HP700/92 Terminal Emulation For the Macintosh
OSX 10.9 Mavericks: The updated version of MS92 for Mac to support Mavericks is available to customers with a current support agreement now. Please call 800-682-0200 or send an email to firstname.lastname@example.org for access. The new version is 220.127.116.11.
NOTE: SUPPORT FOR 64 BIT IS AVAILABLE!
MS92 for the Mac allows your Macintosh to access the data, applications, and storage capacity of your Hewlett-Packard e3000 or other host computers, just as if you were using the HP700/92 terminal. You can connect MS92 for the Mac to your host by direct cable, modem, or local area network. You have options no ordinary terminal can provide. You can log host data to printers or disk files and can automate any task using the TermTalk scripting language. MS92 for the Mac takes full advantage of the advanced capabilities of the Macintosh interface, including multitasking, online help, and cut and paste with the clipboard.
File Transfer Support
MS92 for the Mac facilitates file transfers of any type of file between your Mac and host computer.
Minisoft 92 for the Mac is the only Hewlett- Packard terminal emulator for the Macintosh.
Minisoft 92 for the Mac includes complete serial and LAN connectivity in one integrated package. Minisoft 92 for the Mac features Network Services (NS/VT) and Telnet virtual terminal protocols, allowing connections to HP and UNIX host computers across a wide variety of industry-standard local and wide area TCP/IP networks
HP Terminal Support
- 80,132, or 160 column display
- Configurable scrolling memory
- Line or smooth vertical scrolling
- Row and column counters
- Underline or block cursor
- Line drawing, bold, italic and math character sets
- Configurable HP display enhancements (inverse, underline, half bright, blinking, security)
- Text and background colors (HP2397 color pairs) can be specified via a dialog box or and escape sequence
- Supports all HP and DEC handshaking, including hardware, XON/XOFF, and ENQ/ACK, HP2392, HP700/92, HP ANSI, VT102, emulations.
- Type ahead
Fast and reliable ASCII/Binary file transfers between PC and HP e3000, HP9000 and UNIX host computers. Support for XMODEM, XMODEM CRC 1K, and FTP (File Transfer Protocol). A proprietary file transfer that supports MPE specific information is included.
HPe3000 and HP9000 transfers include:
- Data compression
- Dynamically sized data blocks based on network characteristics
- Support for 7-bit and control character sensitive networks
- Backup of Macintosh files to host
- Archival of host files to Mac. (Mac can act as intermediary in HP to HP file transfer)
Transfers with other hosts
- Includes XMODEM protocol for binary transfer to HP1000 and other non-hp hosts
- Supports Apple Communications Toolbox transfer tools
MS92 for the Mac supports a variety of standards based networking options for the Mac user, including serial, modem, and local area network hardware connections such as HP- NSVT and Telnet. With MS92 for the Mac you can log onto and HPe3000, HP9000, HP1000, DEC VAX and UNIX based systems. Baud rate support is from 300 through 57,600.
MS92 for the Mac’s scripting language is a modern block structured language that provides control of MS92 for the Mac’s communication with the host and interface to the use. The scripts are source and object code compatible on the Macintosh, Windows platform.
The Script Recorder lets you create time-saving scripts by recording all commands typed to the host.
Open the disk image with the password provided by your Minisoft salesperson.
Drag the MS92 application icon to your “Applications” folder.
Support for Intel based Macintosh.
Using Universal Binary images.
This version was Carbonized.
The code is designed for use on OS X only. Use on other Carbon OS versions is not supported.
Prioritization of Feature Transition depends on feedback from customers. Please contact us if a required feature is not yet available or working.
Setting for Ecometry Keys
Break continuous Inverse blocks.
Fix PrintLogTimeout dialog response on no string (LogConfigProc).
Fix change directory
Support for character translations added.
Diagnostic tracing added.
Miscellaneous screen painting improvements.
Store Print Format Settings.
Add Print Log Timeout.
Jaguar (10.3) support.
Better font fitting.
More screen size options.
Fixes and Additions
Serial port baud rates
Button bar fonts fixed
Auto Enter for Return Key
Function Key Label Message
Find start-on-document configuration file
Default serial connected state is now false
Changes to Display Enhancements
Screen Painting improvements
Dialog Box Updates (password, modem progress, ANSI Options, Timed Alert, 9000 file upload, print file)
Network telnet re-connect problem
telnet terminal identification
shift-reset (button bar) toggles “ins line” on
TCP Heart Beat
Host initiated file download to current working directory
TrueType fonts (user selectable whole number sizes) (18.104.22.168)
HP3000 file transfers
Page Setup / Print File
Saving configuration to “User Preferences” folder
Keyboard/Character Set Settings
File Transfer Settings
Utility Menu Items
Keys Menu Items
Log Menu Items
Script Settings (22.214.171.124)
Function Key Settings
Misc. Script Menu Items
Serial & Modem connections (126.96.36.199)
XModem file transfers
XModem file transfers
